| Condition: | New | Sewing Area: | 130*60mm |
|---|---|---|---|
| Feed Mechanism: | Needle Feed | Needle: | DPX 17#18-#25mm |
| Overall Dimensions:: | 1200*800*1170mm | Max. Sewing Thickness: | 0.1-12.7mm |
| Power Consumtion: | 600W Direct Driver Servo Motor | Presser Foot Style: | Pneumatic/electric |
| High Light: | programmable pattern sewing machine,automatic threading sewing machine |
||
| Model | XC-210D |
| Sewing Scope | 130*60mm |
|
Max speed ( rpm )( <3mm ) ) Max speed is variant according to sewing machine |
Recommend speed: 2500 Max speed: 2500 |
| Speed scope ( rpm ) | 200-2500 |
| Feeding | Intermission/Continuous |
| Stitch gap | 0.1-12.7mm ( Min gap 0.1mm ) |
| Max stitch | 8000stitch/pattern |
| Max pattern | 999 |
| Scale | X, Y 10-200% ( min 0.1%) |
| Mirror | X, Y and origin |
| Rotation | 360 |
| Needle | Based on thickness, DP*17 #18 |
| Shuttle | Waver |
| Press foot | Pneumatic |
| Outer press foot move range | 32mm |
| Inner press foot move range | 20mm |
| Inner press foot wove range | 4-10m |
| Main motor | AC Servo 400W/3000rpm |
| Power supply | AC220-240V |
| CBM | 1200*800*1170mm |
| Weight | 110kg |
1.Computer pattern sewing machine can help companies save manpower, reduce wastage , improve quality, increase productivity, improve the company's customer satisfaction, in order to achieve the objective of improve the company's core competitiveness.
2.100% the stitch won't be off because of ourpatent device.
3. Selecting high abrasion resistance spare parts to ensure the stability and longer lifetime for the machines.
4. Movable and reversal presser to act as “ robotic arm” for sewing faster and avoiding getting workers hurt.
5. With automatic parking, automatic thread trimmer, automatic pine line, auto-dial line, automatic presser foot and other functions, easy operation.Regardless of how complex patterns can be a one-time perfect sewing, anyone skilled to operate the machines in a very short period of time.
6.Application items: handbag, suitcase, computer bag, golf bag, shoes, clothing, jeans, sports product, cellphone covers, belts, magic tape, reusable bags, toys, pet products, zipper, leather products. etc. It does not only make the product much more beautiful, but also increase the production efficiency.
