Product Details:
Payment & Shipping Terms:
|
| Condition: | New | Stitch Length: | 0.1-12.7mm |
|---|---|---|---|
| Power: | 500W | Max Sewing Speed: | 2200rpm |
| Needle: | Single Needle, DPx17#18 | Overall Dimensions: | 1200*1060*1170mm |
| After-sales Service: | Overseas Local Service Available In VIetnam, Cambodia And Myanmar | Stitch Formation: | Lock Stitch |
| Mechanical Configuration: | Flat Bed | Press Foot Type: | Pneumatic |
| Feed Mechanism: | Needle Feed | ||
| High Light: | decorative chain stitch sewing machine,knit stitch sewing machine |
||
1, the machine is to be provided with a inclined cranked type looper mechanism,ensure it is in the good durability;
2, condensation stitching can prevent the thread off-line ,which is operated
by lever;
3, stitch length can be easily to adjust;
4, this machine is suitable for many kinds of processes including hemming,welting seam,decorative stitching;
5, accurate stitching performance and durable finished seams are particularly necessary in the chain-stitching
| Model | XC-2516R |
| Sewing Scope | 250*160mm |
|
Max speed ( rpm )( <3mm ) ) Max speed is variant according to sewing machine |
Recommend speed: 2500 Max speed: 2500 |
| Speed scope ( rpm ) | 200-2300 |
| Feeding | Intermission/Continuous |
| Stitch gap | 0.1-12.7mm ( Min gap 0.1mm ) |
| Max stitch | 8000stitch/pattern |
| Max pattern | 999 |
| Scale | X, Y 10-200% ( min 0.1%) |
| Mirror | X, Y and origin |
| Rotation | 360 |
| Needle | Based on thickness, DP*17 #18 |
| Shuttle | Waver |
| Press foot | Pneumatic |
| Outer press foot move range | 32mm |
| Inner press foot move range | 20mm |
| Inner press foot wove range | 4-10m |
| Main motor | AC Servo 400W/3000rpm |
| Power supply | AC220-240V |
| CBM | 1200*1060*1170mm |
| Weight | 176kg |
1.Computer pattern sewing machine can help companies save manpower, reduce wastage , improve quality, increase productivity, improve the company's customer satisfaction, in order to achieve the objective of improve the company's core competitiveness.
2.100% the stitch won't be off because of ourpatent device.
3. Selecting high abrasion resistance spare parts to ensure the stability and longer lifetime for the machines.
4. Movable and reversal presser to act as “ robotic arm” for sewing faster and avoiding getting workers hurt.
5. With automatic parking, automatic thread trimmer, automatic pine line, auto-dial line, automatic presser foot and other functions, easy operation.Regardless of how complex patterns can be a one-time perfect sewing, anyone skilled to operate the machines in a very short period of time.
6.Application items: specially for cap/visor. It does not only make the product much more beautiful, but also increase the production efficiency.
